Product Features
- Bakers Pride Super Deck Y-Series Gas Deck Ovens are designed for high-volume pizza and all-purpose operations.
- This model is constructed with a heavy-duty, .25" angle iron frame, which is fully welded to allow for double-stacking or stacking under an Il Forno Classico.
- The oven chamber features a Lightstone vibrant deck with 8" deck height and independently controlled top and bottom heat dampers for perfectly balanced results.
- Ovens may be stacked two high. Oven exteriors are all heavy- gauge, type 403 stainless steel, and are fully insulated up to 5" (127mm) thick for cooler outer temperatures and consistent interior temperatures.
- The interior oven frame is constructed of a 1/4" (6mm) heavy-duty angle iron frame, completely welded to form a single, unitized section.
- The oven body and lining are then welded to the framework.
- Oven interiors are manufactured of high-heat resistant 16-gauge aluminized steel.
- Doors are fully insulated, spring balanced with tubular steel handles, and will remain open or closed until moved.
- All models feature independent, operator-controlled top & bottom heat control dampers and micro slides for perfectly balanced results.
- Y Series features a 300°-650° F (149°-343°C) throttling thermostat, 8" (203mm) interior deck height with 1 1/2" (38mm) thick hearth baking decks (steel decks optional) and are supported by a 1/4" (6mm) angle iron frame.
- Combination gas control incorporates a manual gas valve, pilot safety, and pressure regulator.
- Easily removable, slide-out, heavy-duty flame diverters distribute the burner flame uniformly in the burner chamber.
- A 3/4" (19mm) NPT gas connection is located on the left side and left the rear of the oven - operator/installer may choose.
- Heavy-duty, 7-gauge hot rolled steel legs are standard and finished with durable Bakestone.
- 1 Year limited part and labor warranty standard.
Product Specs
- WxDxH: 78''x43''x55.2''
- Deck WxDxH: 60''x36''x8''
- Door Type: Solid Door
- Gas Inlet: 3/4 Inches
- Number of Decks: 1
- Temperature Range: 300-650 Degrees F
- Total BTU: 120,000 BTU/Hr
- Spec Sheet
